Y-Piece
Tube Sheet
Lateral

Application Code
Materials of Construction
  * ASME 31.1
  * ASME 16.25
  * ASME Section 9
  * ASME material



  * Carbon Steel : ASTM A105
  * Alloy Steel : ASTM A182-F1, F11, F12,
       F22, F91,F92
  * Stainless Steel :ASTM A182-F30/F304L
      A276, A479, A182-F316 /F316L
  * Inconel Type : Inconel 400, 500, 600,
      625, 825
  * Chrome Moly and Others




Creating the mesh
Lode of Body
Stress analysis
Stress analysis









Size: 16”x16”x12” Material: SA182-F22 CL.3 Weld TYPE





· Line : Feed water system
· Size : 22”~18” Type
· Material : SA182-F22 CL.3 Type
                  SA182-F11 CL.2 Type
                  SA106-C Type





· Line : Feed Water System
· Size : 18”~16” Type
· Material : SA182-F22 CL.3 Type
                  SA182-F11 CL.2 Type
                  SA106-C Type

- Finished Product -

· Line : HP, IP, LP
· Size : HP - OD 1600x497T
                  1765x556T
                  1740x533T
· Material : A266-GR.2 309
· OVERLAY Type
· Line : Feed Water System
· Size : 1266.8x130T
                  1292.2x130T
                  1266.8x127T
· Material : A266-GR.2 309





· Line : HP Main Stream
· Size : OD 446x5200L
· Material : SA182F91
· Item : 90°3D BEND
1. Raw Material→ Pipe Machining
2. Pipe Bending
3. Cooling
4. Shoot peening
5. Magnetic particle Testing
6. Ultrasonic Testing
7. Final Product SA182 F91





· Carbon Steel : ASTM A105
· Alloy Steel : ASTM A182-F1, F11,
                      F12, F22, F91,F92
· Stainless Steel : ASTM A182-F30/F304L
                     A276, A479, A182-F316 /F316L
· Inconel Type : Inconel 400,500,600,625,825
· Chrome Moly. and Others





* INCONEL 600 WELDING

* Water Box Flange

· Material : SA 51670
· Size : OD 3100x2700x120T

· Spindle Diameter : 150mm
· X-Axis ST. : 3000mm
· Y-Axis ST. : 2300mm
· Z-Axis ST. : 1600mm
· W-Axis ST. : 700mm
· WT : 15000kg
